3Dx™ 8.5t Narrow Edge Lifting System

The 3Dx™ 8.5t Narrow Edge Lifting System is a cutting-edge lifting solution designed to meet the challenges of dense reinforcement, thin panels, and heavily reinforced precast elements. Featuring an ultra-narrow neck and head, it enables seamless placement within tightly packed rebar grids, eliminating conflicts while maximising shear and tensile performance.

With dove-tailed nodes and an optimised clutch interface, the system enhances load-bearing capacity and stability during lifting. Its pre-bent void eliminates the need for additional support plates, simplifying installation and reducing setup time. Designed to minimise rotation, spalling, and panel damage, it ensures superior performance in both tension and compression loads, even in thin precast panels. The 3Dx™ 8.5t system has been extensively tested to AS 3850:2024 standards and developed using Finite Element Analysis (FEA) to ensure exceptional strength, durability, and safety.

Its trademarked Anchor Shield coating protects against delamination and corrosion, making it a low-maintenance, high-reliability solution for precasters, builders, and engineers working in high-rise, infrastructure, and manufacturing projects. This system is fully compatible with the 3Dx™ 10-tonne lifting clutch, ensuring secure and efficient lifting operations. Additionally, it features a unique void former, allowing for precise anchor positioning and improved installation accuracy. With its compact design, high shear capacity, and ability to be installed in thin panels, the 3Dx™ 8.5t Narrow Edge Lifting System is the ideal choice for efficient and secure lifting in constrained reinforcement environments.


All Features

• Ultra-Narrow Profile – Designed for seamless placement in high-density reinforcement scenarios & thin panels.
• High Shear Load Capacity – Reduces stress on the anchor and enhances lifting stability.
• Optimised Clutch Interface – Works with the 3Dx 10-tonne lifting clutch for secure handling.
• Dove-Tailed Nodes/Feet – Increases load-bearing area for both tension and compression.
• Unique Void Former – Ensures precise anchor positioning, improving installation accuracy.
• Pre-Bent Void – Eliminates the need for additional support plates, reducing setup time.
• AnchorShield Coating – Protects against delamination and corrosion, extending product life.
• Compliance with AS 3850:2024 – Fully tested to meet stringent safety and performance standards.

All Advantages

• Simplifies Installation – Designed for quick and efficient placement, even in thin panels.
• Increases Productivity – Reduces the number of anchors needed per panel, improving efficiency.
• Minimises Reinforcement Congestion – Can be installed without modifying dense rebar grids.
• Enhances Structural Integrity – Reduces the risk of panel damage and spalling.
• Cost-Effective Solution – Reduces additional reinforcement needs, lowering material costs.
• Versatile Applications – Suitable for high-rise, infrastructure, and manufacturing projects.
• Reliable Performance – Extensively tested under real-world conditions for consistent strength.
• Backed by Engineering Expertise – Supported with technical documentation, case studies, and compliance data.
